CT Whole Body Phantom with Pathologies (PH-2E)

Kyoto Kagaku

Implement theory with practice with pathological findings in this hands-on training phantom

Features:

  • Radiology absorption and HU number approximate to human body
  • Main joints have close-to human articulation
  • Phantom can be disassembled into 10 individual parts

Applications:

  • Plain X-ray / CT /Basic patient positioning

Set Includes:

  • 1 whole body phantom / 1 head supporter / 1 flat head screwdriver/ 1 set of sample X-ray / manual
Clear
Add To Quote
SKU: N/A Category:
Bony Structure
Synthetic skull
Cervical vertebrae
Vertebrae
Clavicles
Ribs
Sternum
Scapula
Coxal bones
Femurs
Internal organs HU number at 80KeV
Brain
  Cerebrum 40
  Mesencephalon 40
  Cerebellum 40
  Cerebral ventricles 10
  Eye balls 20
  Arteries with contrast medium (left half only) 250
Lungs -1000
  Pulmonary vessels 8
Trachea trachea wall: 8 / inside: -1000
Heart PBU-50: 8 / PBU-60: 40
Liver 70
Internal organs HU number at 80KeV
Portal and hepatic veins 40
Pancreas 30
Kidneys 30
Gallbladder 20
Spleen 50
Seminal vesicle 25
Aorta 40
Cava 70
Ureter ureteral wall: 30 / inside: 10
Urinary bladder 10
Prostate 50
Rectum rectum wall: 70 / inside: -800
Sigmoid Colon colon wall: 70 / inside: -800

Set Includes

1 whole body phantom 1 hand-fixture belt
1 head supporter 1 set of sample X-ray data (DVD)
1 flat head screwdriver manual

Size:

  • 165 cm /65in height
  • 50 kg / 110 lb

Materials:

  • Soft tissue: urethane based resin (density: 1.06)
  • Synthetic bone: epoxy resin (density: 1.31)
  • Skull: epoxy resin (density:1.11)
  • *Phantom has no metal parts or liquid structure
Type

CT Whole Body Phantom with Pathologies, head for PH-2E with head stand, trunk for PH-2E, Assembling bolt/nut set for PH-2/2B/2E/79, left hand for PH-2 & 2B, right upper arm for PH-2 & 2B, right thigh for PH-2 & 2B, left thigh for PH-2 & 2B, right foot for PH-2 & 2B, left foot for PH-2 & 2B, storage cases for PH-2/2B/2E (a pair), body plates for PH-2/2B/2E/60 (BMI 32), body plates for PH-2/2B/2E/60 (BMI 40)
