Consistent image quality for clinical review
With the highest resolution in Barco’s Eonis range, the Eonis Color 8MP gives clinicians the space to review medical images, patient records, and clinical information side by side. Its integrated front consistency sensor automatically adjusts and maintains image consistency when the display is powered on. A dedicated pathology setting with sRGB color calibration supports accurate representation of whole slide images in pathology workflows. Through QAWeb Enterprise, image quality can also be managed centrally across displays, helping healthcare organizations maintain consistent review conditions with less manual intervention.
One cable, full workstation connectivity
USB-C Alt Mode turns the Eonis Color 8MP into a central docking hub for the clinical workstation. Video, data, power, and network connectivity can all run through a single cable, reducing cable clutter at the desk or bedside.
The display supports KVM switching, allowing users to switch between up to three connected input devices, such as PACS workstations or laptops, directly from the display. Picture-by-picture functionality makes it possible to divide the 8MP screen into two independent 4MP zones or view two workstations side by side for direct comparison. A built-in LAN port and daisy chaining further simplify workstation setup and connectivity.
Built to last, built responsibly
The Eonis Color 8MP is designed for long-term value, with a 3-year warranty and Barco’s A+ ecoscore. Sustainability features include automatic standby mode, recycled plastic content, halogen-free components, recyclable packaging, and unpainted housing to support easier recycling.
High image quality
Eonis 8MP offers you 8 megapixels of screen resolution, the highest in our Eonis range. This makes it an ideal choice for healthcare professionals seeking second opinions, emergency or trauma assessments, or referrals, which are not primary diagnoses. Moreover, the display incorporates an innovative front consistency sensor that seamlessly adjusts image quality whenever you power it on.
Additionally, Eonis 8MP has a pathology setting that triggers sRGB color calibration, resulting in excellent images with accurate color representation.
Virtual collaboration was never this easy
The Eonis 8MP extends its capabilities beyond its core functions by providing multimedia features. These streamline intra-hospital and virtual communication among healthcare practitioners, discussing a patient’s medical history, electronic medical records and clinical images.
- Built-in camera, microphone, and speakers
- Consistent images and centralized quality assurance
- KVM for seamless switching between workstations
These features promote effective communication across locations and clinical disciplines, making Eonis 8MP an excellent tool for teleconsultations with patients as well.
A+ ecolabel for Eonis Color 8MP
The Eonis Color 8MP has been subjected to Barco’s ecoscoring protocol and has received an A+ rating. Some key factors that contributed to this rating are:
- Automatic standby mode when device is not in use
- Use of plastics containing 30% recycled content >50% halogen-free cables & >65% halogen-free PCBs
- >90% recyclable packaging
- Unpainted housing to make recycling easier
Specifications
| Specification | Eonis Colour 8MP |
|---|---|
| Warranty | 3 Years |
| Active Screen Size (H x V) |
708 mm x 399 mm (27.9” x 15.7”) |
| Screen technology | IPS |
| Diagonal size | 812.80 mm (32.0”) |
| Aspect ratio | 16:9 |
| Resolution | 8MP (3840 x 2160) |
| Luminance (DICOM calibrated) | 500 cd/m2 (300 cd/m2) |
| Contrast ratio | 1000:1 |
| Screen protection | N/A |
| Sensor technology | Front consistency sensor |
| Video input signals | DisplayPort 1.4 (2x) |
| Medical device regulations | “FDA: Medical Device Class II EC: Medical device class IIa (Regulation (EU) 2017/745” |
| Package includes | Eonis display, 3-year all-inclusive warranty, QAWeb |
| Options Additional | MXRT graphics controller, Intuitive Workflow toolset, Additional service and warranty options |
Barco
Enabling bright outcomes
Imagine a way to see, sense, and share the intangible. It’s what happens when big data becomes knowledge. When images become insight. And when experiences come to life. That’s what Barco is all about.
Focused on transforming the delivery of care, Barco connects healthcare professionals at every patient touchpoint, from the imaging room to radiology, through specialist consultations and into the surgical suite. We offer a network of medical imaging solutions that deliver the complete picture to support more informed decisions, when and where it matters most.
More than a medical display
Increasing image volumes, the growing complexity of studies, and physical discomfort while reading are the three biggest challenges radiologists face today. That is the conclusion of a 2014 survey conducted by The MarkeTech Group. The solutions? Improved image quality (91%), a more efficient workflow (77%), and better display ergonomics (70%), as indicated by radiologists themselves.
We are able to provide capabilities that can improve the reading experience in all aspects: speed, accuracy, intuitiveness, flexibility and ergonomics. How? By offering a complete imaging solution – high-quality display, ultra-fast controller for fast image loading and manipulation and automated calibration & QA to ensure peak performance and uptime – in which all components function smoothly as a unified system.
Barco’s integrated technology platform enables us to develop a unique set of Intuitive Workflow features resulting in increased reading accuracy and decreased reading time. Only Barco display systems offer this diagnostic toolset, which adds a new dimension to radiologists’ workflow by streamlining frequent tasks with automated features. Designed to help you speed through your workload with ease, these builtin, easy-to-use functions appear at your command, seamlessly paving the way for effortless productivity and working comfort.
