MDPC-8127

SKU: BAR-MDPC-8127

Meet MDPC-8127, our ultra-high definition medical grade display designed exclusively for digital pathology. With regulatory clearances for use in digital pathology including primary diagnosis, it’s the first display that you can confidently integrate into your digital pathology workflow with multiple whole slide imaging systems.* Work with superior imaging technology and analyze your histological samples confidently, with unprecedented visual richness.

Add To Quote
SKU: BAR-MDPC-8127 Category: Brand:

Description

Your slides, visualized as never before

Trust your display like you trust your expertise, with the 27-inch, ultra-high definition display.

  • Extremely sharp and consistent images
  • Large visible slide area, at all viewer zoom levels
  • 1.07 billion possible colors, tailored to digital pathology images
  • Effortless panning & zooming with minimal blurring
  • High-precision touchpad for improved productivity

Ultra-high definition

The 8 megapixel, ultra-high definition display is fully equipped to offer you diagnostic clarity. It has a high pixel density and color per-pixel-uniformity, so slide images are displayed extremely sharp and consistent. This combination of technologies offers you more visible slide area to work with, at all viewer zoom levels, to help spot details more easily and aid in timely analysis.

Constant quality

The MDPC-8127 is equipped with an I-Guard front sensor that protects your display’s image quality during every reading session. In concert with QAWeb Enterprise, color management within your digital pathology viewing software, using ICC profiles, is automatically supported, and pathology images are shown consistently across your enterprise and telepathology reading sites.

Specifications

Specification MDPC-8127
Warranty 5 years
Active Screen Size
(H x V)
569 x 335 mm
(22.4 x 13.2″)
Screen technology IPS LCD with LED
Diagonal size 684mm (27″)
Aspect ratio 16:9
Resolution Native 8MP (3840 x 2160 @ 120Hz)
Luminance 450 cd/m2 (max. 850 cd/m2)
Contrast ratio 1000:1
Color depth 10 bit
Color gamut 132% sRGB
Sensor technology I-Guard & ambient light sensors
Imaging technology RapidFrame, PPU
Video input signals 2x DisplayPort 1.2
Medical device regulations FDA: Medical Device Class II EC: Medical device class IIa (Regulation (EU) 2017/745″
Package includes MDPC-8127, QAWeb Enterprise, Barco touchpad, 5-year warranty
Options MXRT display controller, Intuitive Workflow Toolset Additional warranty and service options
