Features
- Compact size allows imaging in a single scan, saving time and simplifying the process.
- To ensure the verticality of the entrance beam, two horizontal wires are embedded and the supporting guide frame secure the transducer in its home position for testing,
- For monthly basic quality test, as well as longer term quality assurance to maintain consistency of the performance of scanners and transducers.
- Stable and long-life material of the phantom *proved by 5-year-test
- To maintain the internal temperature of the phantom (23°C to 26°C), a thermometer is provided.
Training skills / Applications
- Image quality and aging of the transducer
Materials
- Urethane elastomer, acryl, nylon Latex free
Size (approx.)
- W10.3×D5×H8cm
(W4×D1.97×H3.15in.) - 0.33kg/ 0.72 lbs
Material Features
- Sonic velocity: 1434(±1)m/ sec at 25℃
- Attention coefficient: 0.59 dB/ cm MHz at 25℃
- Acoustic impedance: 1.37 rayl at 25℃
Set Includes
| Quantity | Item |
|---|---|
| 1 | Phantom |
| 1 | Thermometer |
| 1 | Instruction Manual |
