34in 2 Panel Image Tailor Mobile Positioning Partner

Reina Imaging

The Image Tailor Mobile DR Positioning Partner is a multi-functional positioning device that allows hips to ankle exams to be performed in the most difficult imaging environments. Its compact footprint makes it simple to drape and keep sterile when used in surgery and easy to store when not in use. Imaging hips to ankles can be a challenge, and there are several issues that one must consider: the process of care, patient safety, efficiencies, clinical outcomes, and, of course, cost. Using multiple image receptors or one single long-format detector increases cost dramatically.
The Image Tailor stitching cabinet allows for quick and easy manual stitching with a single DR panel allowing the healthcare provider’s facility to leverage the full value from a small format detector.
Add To Quote
SKU: RNI-POSPIT2 Category:

PRODUCT ADVANTAGES

  • Designed for precise fitment of your 14x17in. or 17x17in. image receptor
  • Features an image receptor tray and built in detents to speed workflow and reduce patient hold times
  • Factory configured overlap area and available embedded markers for every OEM panel and stitching software requirement
  • Greatly improves total cost of ownership for single detector rooms
  • Removable custom detector holder available with or without a grid allows the DR panel to be shared for portable imaging and free exposures without ever removing it from the holder
  • Simple push-button mechanism engages the zero-gravity lift assist mechanism in the vertical position and disengages for the landscape and under-table positions
  • Available with Reina Imaging’s sliding Easy Reader™ radiographic ruler

SIMPLY SMART STITCHING

Stitching.

Imaging the full spine or hips to ankles can be a challenge. There are several issues that one has to consider such as process of care, patient safety, efficiencies, and outcomes. Whether you use a single shot long detector or multiple exposures with a 14×17 detector, we have a solution to help stitch your DR images effectively every time.

PRODUCT DIMENSIONS

  • Product Weight: 196 lbs (89kg)
Overall Dimensions 30 x 23.25 x 40 in. (76.2 x 59 x 101.6 cm)
Total Vertical Stroke 44 in. (111.75 cm)
Pneumatic Piston Vertical Stroke 19 in. (48.25 cm)
Horizontal Arm Vertical Stroke 25 in. (63.5 cm)
Horizontal Stroke (Telescoping Arm) 6 in. (15.25 cm)
Max. Height Active Imaging Area – Portrait 75.5 in. (191.77 cm)
Min. Height Active Imaging Area – Portrait 3 in. (7.5 cm)
Max. Height Active Imaging Area – Landscape 66.5 in. (168.91 cm)
Min. Height Active Imaging Area – Landscape 8.25 in. (20.955 cm)
Max. Height Active Imaging Area – Undertable 67.5 in. (171.5 cm)
Min. Height Active Imaging Area – Undertable 23.5 in. (60 cm)
