PH-72 MRI Breast QA Phantom with storage (PH-72)

SKU: KKG-PH-72-41936-000

An innovative phantom with shape of breasts for detailed QA in Breast MRI

Features:

  • Quantitative evaluation of Breast MRI with breast coils
  • Adjustable height of the phantoms in the range of 10cm to fit the depth of the coils
  • Horizontal position of the phantoms can be set arbitrarily on the 30cm length slit

Set Includes: 2 breast MRI evaluation unit (2 types, 1 each) / 1 adjustment bolts / 1 supporting plate / 1 storage case

Add To Quote
SKU: KKG-PH-72-41936-000 Category: Brand:

Description

Realizing Education That Inspires Through Manufacturing

Founded in 1891, Kyoto is the world’s only manufacturer of anatomical models, simulators, and imaging phantoms. Made in Kyoto, Japan and trusted in over 60 countries around the world. Passing on cultural heritage through technologies for restoring and replicating cultural assets.

Applications

  • MRI

Test Summary

  • Spatial resolution
  • Quantitative evaluation of ADC on test pieces of tissue substitute

Dimensions:

  • 30 x 40 x 26cm / 11.8 x 15.7 x 10.2inch

Materials:

Acrylic Resin

Set Includes

1 breast MRI evaluation unit
(2 types, 1 each)
1 adjustment bolt
1 supporting plate
1 storage case
