CT Abdomen Phantom (PH-5)

SKU: N/A

The phantom facilitates study of image fusion between CT and ultrasound in combination with US-1 Echozy*. New variation for MECT has been added.

Features:

Two variation to meet your requirements:

  • CT type (no contrast enhancement)
  • MECT type (vessels with 13mgI/ml** iodine and the liver of multi-energy CT compatible material).
    **Concentration of iodine can be custom-ordered.

Applications:

  • CT / Multi energy CT

Set Includes:

  •  1 abdomen phantom / 1 set of sample X-ray data (DVD) / 1 storage case / manual
Add To Quote
SKU: N/A Categories: , Brand:

Description

Realizing Education That Inspires Through Manufacturing

Founded in 1891, Kyoto is the world’s only manufacturer of anatomical models, simulators, and imaging phantoms. Made in Kyoto, Japan and trusted in over 60 countries around the world. Passing on cultural heritage through technologies for restoring and replicating cultural assets.

Anatomy

lungs (no internal structure) hepatic vein aorta
heart (no internal structure) hepatic artery IVC
liver kidneys spinal column
portal vein pancreas ribs
gallbladder spleen

Size:

  • W27xD16xH30cm / W10.6xD6.3xH11.8in
  • 12kg / 26.4lb

Materials:

Soft tissue: urethane based resin (density: 1.06) / Synthetic bone: epoxy resin (density: 1.31)

Set Includes

1 abdomen phantom 1 storage case
1 set of sample X-ray data (DVD) 1 manual
