Description
4K IPS Display for Surgical Locations
The 4K high-resolution monitor provides image accuracy, user convenience and reliability for surgery environments.
31.5” (80.01cm) 4K IPS
Wide Viewing Angles
With a 31.5-inch 4K IPS display, the LG surgical monitor provides clear images from wide viewing angles.
sRGB 115% (Area), Over 99% (Coverage)
The 32HL710S, supports sRGB 115% (Area) and over 99% (Coverage) in accordance with the CIE colour system and DICOM standard Part 14. It is designed to support accurate colour reproduction and depth perception during surgery.
Brightness Stabilisation
The LG surgical monitor with Brightness Stabilisation is able to maintain constant brightness. Its sensor monitors the local lighting conditions and optimises brightness to assist in surgical review.
HDR10 Support
The LG surgical monitor is designed to work with HDR-supported medical devices such as endoscopic cameras.
Multiple Images on One Screen
The 32HL710S supports up to 4 PBP and PIP (Picture in Picture) to enable viewing of images from multiple input sources.
Multiple ports enable the connection of several devices to enable viewing of data such as endoscopic camera images, vital sign imagery and fluoroscopic imagery.
Failover Input Switch
When the main source is missing, the display will automatically switch to a failover (backup) source and restore the main source once the signal is back. You can set the main input and failover input in the setting menu of monitor.
Image Adjustment
The 32HL710S has a Mirror & Rotate function to assist viewing convenience.
Images can be rotated up to180 degrees or a mirror image presented to assist with operating efficiency.
Images can be rotated up to180 degrees or a mirror image presented to assist with operating efficiency.
IP Rated for Protection
To assist with protection against contact with bodily fluids, the LG surgical monitor has an IP35 rating for the front of the monitor and IP32 rating for the body of the unit.
Specifications
| Specification | LGE-32HL710S-W |
|---|---|
| Warranty | 3 Years |
| Active Screen Size (H x V) |
27.5 x 15.4 in (697 x 392 mm) |
| Screen technology | IPS |
| Diagonal size | 31.5 in (800 mm) |
| Aspect ratio | 16:9 |
| Resolution | 4K UHD (3840 x 2160) |
| Luminance | 800 cd/m² Typ. (500 cd/m² Stabilised) |
| Contrast ratio | 1000:1 |
| Screen protection | Protection Glass (1.6t, Anti-Reflection/Fingerprint) |
| Sensor technology | Backlight Stability Sensor |
| Surgical Imaging Technology | DICOM Compliant, Brightness Stabilization, HDR10, Failover Input Switch, PBP (2/3/4), PIP, Mirror & Rotation Mode |
| Inputs | DisplayPort, HDMI, DVI3G-SDI, 12G-SDI RS-232, USB |
| Outputs | DisplayPort, DVI, 12G-SDI, USB |
| Colour Gamut (Typ.) | sRGB 115% (Area) sRGB Over 99% (Coverage) |
| IP Rating | IP35 Front / IP32 Rest |
| Certifications | IEC (IEC 60601-1 / IEC 60601-1-2), EN (EN 60601-1 / EN 60601-1-2), cUL (ANSI/AAMI ES 60601-1, CSA CAN/CSA-C22.2 NO. 60601-1), FDA (510(K) (Class I)), RoHS, REACH, WEEE
IEC (IEC 60950-1 & IEC 62368-1 / CISPR 32, 35), EN (EN 62368-1 / EN 55032, 55035) |
