Description
High Definition Imaging
High Resolution Display for Breast Imaging
Diagnostic Monitor 21HQ613D displays radiological images, including full field digital mammography and digital breast tomosynthesis, with a brightness of 1,100 cd/m² and a contrast ratio of 1,800:1. Moreover, this monitor showcases vivid colour, high definition mammography and breast tomosynthesis images including breast MRI, CT scans and ultrasound, ensuring versatile performance across various medical imaging modalities.
Multi-resolution mode
Set the resolution mode to fit your needs
The various resolution modes (5/3/2MP) of the 21HQ613D allow users to customise their resolution to better fit their respective needs.
Consistency in medical images
Internal front calibration sensor
The front-sensor, supported by calibration software, enables calibration without the need for additional measuring equipment, ensuring stable image quality.
Focus on the region of interest
Focus view mode
Highlight specific parts of the medical image with Focus view mode. Users can easily select and focus on areas of concern with max brightness of screen, while darkening the rest.
Pathology mode
As if you were looking into a microscope
With Pathology mode, this diagnostic monitor provides image clarity and accuracy as if you were looking at a microscope.
Intuitive Control
5 Hot Keys
The 5 Hot Keys make changing between screen modes easier and more intuitive than operating through an OnScreen menu. They provide a fast and easy way to operate while working, allowing you to change mode and lighting settings without disrupting your workflow.
Convenient power management
Presence sensor
The presence sensor automatically turns off the display when no motion is detected for 5 minutes.
Daisy chain
Simple connection.
Less clutter in your workspace.
Make your workspace productive with the Daisy Chain setup. You can reduce clutter on your desk and simplify cable management, leading to a productive workspace.
User-friendly monitor stand
21HQ613D is designed to be adjustable for the posture of users’ image review. The ergonomically designed stand allows users to freely adjust the tilt, height, and swivel. It also features a bi-directional auto pivot function for added flexibility.
Ideal diagnostic workspace
Down light & Wall light
Down /Wall light mode enhances readability of documents below the monitor even in low-light environments.
Auto luminance sensor
Automatically adjusts screen brightness
21HQ613D features an Auto luminance sensor which adjusts screen brightness automatically for more readability according to levels of surrounding light.
Specifications
| Specification | LGE-21HQ613D-B |
|---|---|
| Warranty | 5 years |
| Active Screen Size (H x V) |
13.3 x 16.6 in (338 x 422 mm) |
| Screen technology | IPS |
| Diagonal size | 21.3 in (541 mm) |
| Aspect ratio | 4:5 |
| Resolution | 5MP (2048 x 2560) |
| Luminance | 1100 cd/m² Typ. (600 cd/m² DICOM) |
| Contrast ratio | 1800:1 |
| Screen protection | N/A |
| Sensor technology | Internal Front Sensor, Backlight Stability Sensor |
| Diagnostic imaging technology | DICOM Compliant, Brightness Stabilization, Brightness Uniformity Correction, Multi-resolution Mode (5/3/2MP), Pathology Mode, Focus View Mode, Light Box Mode, Auto Luminance Sensor, Down Lighting & Wall Lighting |
| Inputs and Outputs | DisplayPort (2x), DVI-D, USB Hub and Daisy Chain |
| Certifications | IEC (IEC 60601-1 / IEC 60601-1-2, IEC 60950-1 & IEC 62368-1 / CISPR 32, 35), EN (EN 60601-1 / EN 60601-1-2, EN 62368-1 / EN 55032, 55035), cUL (ANSI/AAMI ES 60601-1, CSA CAN/CSA-C22.2 NO. 60601-1), FDA (510(K) (Class II)), RoHS, REACH, WEEE |
