Description
Backlight stabilization system
The built-in integrated backlight sensor continuously monitors the brightness of the backlight. It can quickly achieve brightness stability at startup and automatically compensate for changes in ambient temperature and brightness loss caused by long-term use, maintaining brightness consistency throughout the product life cycle.
Ambient Light Adaptive System
With built-in integrated front ambient sensor, the ambient environment can be monitored continuously, the brightness can be adjusted to a proper level automatically to ensure the display is compliant with DICOM standard under any ambient environment The diagnostic accuracy is increased and discomfort and eye-strain can also be avoided.
Comply with DICOM international standard
Accurately display medical images and the smallest details, maintain the display consistency of different monitors, and display consistency between monitors and different imaging equipment, ensuring diagnostic accuracy.
Continuous Quality Calibration System
The front-end integrated sensor monitors and corrects the grayscale and color of the screen, continuously and automatically ensures the accuracy of medical image display and centralized management through the network.
Specifications
| Specification | BDT-C310S |
|---|---|
| Warranty | 5 years |
| Active Screen Size (H x V) |
17.1 x 12.8 in (433 x 325 mm) |
| Screen technology | IPS |
| Diagonal size | 21.3” (541 mm) |
| Aspect ratio | 4:3 |
| Resolution | 3MP (2048×1536) |
| Luminance | 1100 cd/m² Typ. (500 cd/m² DICOM) |
| Contrast ratio | 2000:1 Typ. |
| Screen protection | Anti-Glare, 3H Coating |
| Sensor technology | Internal Front Sensor, Backlight Stability Sensor |
| Diagnostic Imaging Technology | Backlight Stabilization System, Compliant with DICOM Standard, Continuous Quality Assurance System, Ambient Light Adaptive System, Quality Assurance Software, Low Blue Light Technology, Primary Screen Adaption |
| Input and Outputs | DisplayPort, DVI-D |
| Certifications | CE, FDA |
